CL624J
This CL624J is recommended to be used in tight spaces where a higher pull-out strength is needed. This part is according to military spec.
We recommend using the Broaching Tool BT453-4 to insure a proper installation in hard materials.
Materials
Specifications
- Material
- Stainless Steel passivated
- Amount of clins
- 4
Dimension information
Dimensions
- Internal thread Ø d
- 3/8 - 24 UNJF
- External thread Ø d
- 1/2 - 13 UNC
- Shear Engag.
- 0.429 Inch²
- Length (L)
- 0.5
- Locking Depth (Z)
- N/A
Installation
- Tap Drill D1
- 0.453
- Countersink D3
- 0.51
- Thread D2
- 1/2 - 13
- Min. Depth T
- 0.56
Old removal method
- Drill Diameter
- 13/32
- Drill Depth
- 3/16
